Detail: Graph Menu (Graph Box)

The Graph menu in the Graph box provides tools for analyzing and manipulating graphs you already have. It is especially useful for large graphs, where structural properties and admissible paths are not immediately obvious from the visual layout.

From a Graph box, open the Graph menu in the menubar to access the commands below.

Graph Menu

Graph Menu

Random Graph

Graph β†’ Random Graph

Creates a new random graph directly in the current Graph box. You can choose among several random-graph generators, typically including:

  • DAG – random directed acyclic graph with user-specified parameters such as:

    • Number of measured nodes,

    • Number of additional latent confounders,

    • Number of edges,

    • Maximum indegree, outdegree, and total degree,

    • Whether the graph should be connected.

  • MIM – random Multiple Indicator Model, with latent variables and measured indicators.

  • Scale Free – random scale-free graph with a heavy-tailed degree distribution.

After choosing a generator, you can edit its parameters in a dialog; clicking Done replaces the current graph with a newly generated one.

Graph Properties

Graph β†’ Graph Properties

Displays a summary of graph statistics, including for example:

  • Number of nodes (and number of latent nodes),

  • Number of edges and adjacencies,

  • Number of two-cycles,

  • Number of directed, bidirected, and undirected edges,

  • Maximum indegree, maximum outdegree, and maximum degree,

  • Average degree and density,

  • Whether the graph is acyclic.

This is a convenient way to check basic properties of a large graph at a glance.

Underlinings

Graph β†’ Underlinings

Shows any underlinings produced by certain algorithms (for example, CCD or CPC), which mark special edge patterns or decisions. If the current graph contains underlinings, they are listed here for inspection.

Paths

Graph β†’ Paths

Opens the Paths dialog, which lets you list various paths and path-based sets between a chosen pair of nodes (From, To), optionally conditioned on a set of variables. A drop-down menu lets you select what to list:

  • Directed Paths – directed paths from the source to the target.

  • Semidirected Paths – paths that are directed β€œforward” apart from possible undirected edges.

  • Treks – paths without colliders.

  • Confounder Paths – paths reflecting common causes between variables.

  • Latent Confounder Paths – paths where confounding is due to latent variables.

  • Cycles – cyclic paths.

  • All Paths – all (simple) paths between the chosen nodes.

  • Adjacents – nodes adjacent to the chosen node(s).

  • Adjustment Sets (for Total Effect) – sets of variables that qualify as adjustment sets for the total effect from X to Y.

  • Direct-Effect Adjustment Sets (Edge-Specific) – edge-specific adjustment sets for direct effects.

  • Amenable paths – semidirected paths from X to Y that start with a visible edge out of X; an adjustment set should not block any of these paths.

  • Backdoor paths – non-causal (backdoor) paths from X to Y that should be blocked by an adjustment set.

This tool is central for understanding causal paths and potential adjustment sets in complex graphs.

Highlight

Graph β†’ Highlight

Highlights particular structures or edge types in the current graph, such as:

  • Directed, bidirected, undirected, partially oriented, or non-directed edges,

  • Triangles and maximal cliques,

  • Cycles and β€œalmost cyclic” paths,

  • Latent nodes or measured nodes.

Highlighting is especially useful for spotting patterns that are hard to see visually in large graphs.

Check Graph Type

Graph β†’ Check Graph Type

Tests whether the current graph satisfies the conditions for one of several standard graph classes:

  • DAG (directed acyclic graph),

  • CPDAG (completed partially directed acyclic graph),

  • PDAG (partially directed acyclic graph),

  • MAG (maximal ancestral graph),

  • PAG (partial ancestral graph).

Choosing an option runs the check and reports whether the current graph qualifies. This is helpful when you have manipulated a graph and want to confirm that it is still a valid member of a particular class.

Manipulate Graph

Graph β†’ Manipulate Graph

Provides tools to transform the current graph while staying within a particular equivalence class or graph type. Options include, for example:

  • For CPDAGs:

    • Revert to unshielded colliders,

    • Apply Meek rules,

    • Revert to CPDAG,

    • Pick a random DAG in the CPDAG.

  • For PAGs:

    • Revert to unshielded colliders in a PAG,

    • Apply the final FCI rules,

    • Revert to PAG,

    • Pick a Zhang MAG represented by the PAG.

  • Additional utilities:

    • Correlate exogenous variables,

    • Uncorrelate exogenous variables.

These operations are useful for exploring particular members of an equivalence class or enforcing standard orientation rules.

PAG Edge Specialization Markups

Graph β†’ PAG Edge Specialization Markups

Adds or removes PAG edge specialization markups for PAGs and provides help on how to interpret them:

  • Add/Remove PAG Specialization Markups – toggles specialized edge markings that encode additional information about possible underlying MAGs.

  • PAG Edge Type Instructions – opens a short help dialog explaining the meaning of these specialized PAG edge types.

This menu is mainly used when working with PAGs and their refinements, for more detailed causal interpretation.

Summary

The Graph menu turns the Graph box into a powerful graph analysis workbench, letting you:

  • Generate random graphs for experiments or teaching,

  • Inspect structural statistics,

  • Explore all relevant causal paths and adjustment sets,

  • Highlight complex substructures,

  • Check and manipulate graph types,

  • And work with specialized PAG annotations.

It is particularly valuable when working with large or intricate graphs where visual inspection alone is not sufficient.
